Model 2800 Large Size Machine /Folding Gluing

  • Ditch Folder Gluer

  • Semi-Automatic Folder Gluer

  • Electric

  • Cartons

  • Film

  • computer contro

  • CZXY

  • Hebei Cangzhou

  • 8441809000

  • 10sets/Month

  • Available | Customized Request

BZD2800 Semi-automatic Folder Gluer
Model 2800 Large Size Machine /Folding Gluing
Model 2800 Large Size Machine /Folding Gluing
Model 2800 Large Size Machine /Folding Gluing

Main Configuration:
Semi-automatic gluer is new-type environmental equipment, mainly used in carton sticking, abandon the traditional copper stapling method, raised the productively, and the product quality is good.
Main machine frame: machine frame, ascend and descend workable, front part convey equipment, front part amending equipment, middle part convey equipment, middle part press together equipment, finished product side output equipment, electrical controlling equipment.
Usage and Characteristic:
Simple and reliable operation system
Whole novel smooth design
Quick change of size
Automatic counting, strapping set
Gluing 240mm or so for the carton width plus height.
Parameter and specification BZD2800
Max size (length +width)×2 2800mm
Min size (length +width)×2 340mm
Max size (width +height)×2 1515mm
Min size (width +height)×2 240mm
Paper height 1000mm
Engine power 2.2kw
Machinery speed 60m/min

Related Products:
Model 2800 Large Size Machine /Folding Gluing

Delivery picture:
Model 2800 Large Size Machine /Folding Gluing
