Corrugated Box Folder Gluer Packing Machinery

Quantity:
  • Carton Folder Gluer
  • Automatic Folder Gluer
  • Electric
  • Film
  • 2-8mm
  • 60m/Min.
  • CZXY-2400
  • Frequency Control of Motor
  • 2800mm
  • Engineers Are Available Service Abroad.
  • Electric Adjustment
  • Used for Corrugated Box
  • Very Easy
  • Omron
  • Plastic Film, Container.
  • Power: 2.2kw, Weight: 7T,Dimension:12000*4810*2530
  • Xiaoyuan
  • Cangzhou City, Hebei Province
  • 8441809000
  • 10sets/Month
  • Available | Customized Request

Corrugated box folder gluer packing machinery
Corrugated Box Folder Gluer Packing Machinery
Corrugated Box Folder Gluer Packing Machinery
Corrugated Box Folder Gluer Packing Machinery


CZX-BZD2800 Semi-automatic Folder Gluer
Main Configuration:
Semi-automatic gluer is new-type environmental equipment, mainly used in carton sticking, abandon the traditional copper stapling method, raised the productively, and the product quality is good.
Main machine frame: machine frame, ascend and descend workable, front part convey equipment, front part amending equipment, middle part convey equipment, middle part press together equipment, finished product side output equipment, electrical controlling equipment.
Usage and Characteristic:
Simple and reliable operation system
Whole novel smooth design
Quick change of size
Automatic counting, strapping set
Gluing 240mm or so for the carton width plus height.

Parameter and specification CZXY-BZD2800
Max size (length +width)×2 2800mm
Min size (length +width)×2 340mm
Max size (width +height)×2 1515mm
Min size (width +height)×2 240mm
Paper height 1000mm
Engine power 2.2kw
Machinery speed 60m/min



Related Products:
Corrugated Box Folder Gluer Packing Machinery


Finished Box picture:
Corrugated Box Folder Gluer Packing Machinery

Delivery picture:
Corrugated Box Folder Gluer Packing Machinery
