/My-1100 Automatic Creasing Die Cutting Machine Made in China

Quantity:
/My-1100 Automatic Creasing Die Cutting Machine Made in China
/My-1100 Automatic Creasing Die Cutting Machine Made in China
/My-1100 Automatic Creasing Die Cutting Machine Made in China
/My-1100 Automatic Creasing Die Cutting Machine Made in China
/My-1100 Automatic Creasing Die Cutting Machine Made in China
/My-1100 Automatic Creasing Die Cutting Machine Made in China
  • Mechinery&Hardware

  • High-Speed Slitting Machine

  • Round Knife Cutting

  • Cutting Part

  • Film

  • Paperboard Making Machine

  • Paperboard Making Machine

  • Paper

  • Paper

  • Pressed Flat Die Cutting

  • 1100*780m

  • 400*370mm

  • 1090*770mm

  • 5mm

  • 300n/Cm2

  • ±0.1mm

  • 6500 Sheets/H

  • 1100(Above The Level)

  • 17kw

  • Plastic Film, Container

  • Wall thickness: 50mm

  • CZXY

  • Hebei, China

  • 8441809000

  • 15sets/Month

  • Available | Customized Request

MY-1100 automatic creasing die cutting machine made in China

/My-1100 Automatic Creasing Die Cutting Machine Made in China
Specifications

Automatic die cutting machine
1 High die cutting precision
2 Reasonable price
3 Delivery on time
4 Quality guarantee


Machine Introduction:

1. Equipped with pneumatic clutch and pneumatic locking plate.
2. Fidek paper feeding:Suitable for a variety of paper, high-speed stability, and easy to adjust. ,4-8 reliable separation nozzle means so that it is more stable and more accurate high speed. Ministries gas individually adjustable, so that the operator more handy. Double sheet detection mechanism extends to the outside of the machine, the overall adjustment. Direction with a stretch drive section safety cover to prevent entanglement.

3. Automatic adjusting paper feeding, paper collecting and paper aligning.
4.Automatic gripper type equipped the tooth row, open bite adjustable, under the help of paper, cardboard can run smoothly. Automatic suction suck about using leading edge of paper, tooth row gripper-style, curved cardboard and tissue paper can also be passed no scratches.
5. Pneumatic take samples when machine working, can check the die cutting effect at any time.
6. Dusting air guns, can effectively remove the template, and dust inside the device.
7. Automatic lubricating can add lubricating oil on the chain gear according to time, extended the working life of machine.
8. Using alarm bells agencies in warning tone when the device is turned to raise safety warning.
9. Equipped with a precision of detection (Taiwan Riko) fiber optic switch, the paper is in place to detect and avoid paper waste.


Product Overviews
/My-1100 Automatic Creasing Die Cutting Machine Made in China

/My-1100 Automatic Creasing Die Cutting Machine Made in China
/My-1100 Automatic Creasing Die Cutting Machine Made in China





Carton box finished picture:
Our Services

1. OEM service are available.
2. TradeManager online, also contact by Email, Skype. MSN.
3. To solve problems by pictures/videos.
4. Engineers are available service abroad.
PS: Normally our machines are uneasy to broken because of our professional machine making team and strict QC team, we will also send you our manual and video, what you need to do is just learn some basic thing such as machine maintenance.

Best regards,
Carina
CZXY-PACK CARTON MACHINERY MANUFACTURE
Xiazhuang Industry Area, Cangzhou City, Hebei Province, China
Website: http://czxypackmachine.en.made-in-china.com
Made-in-China Website:http://czxypackmachine.en.made-in-china.com


Fax/tel:0317-7805687
