Double pieces folder gluer machine for 3ply corrugated offset box forming
I.Main technical features
HX-2400B series semi automatic double paste box machine is our company accoeding to the change of market demand at domestic and abroad, a comprehensive analysis of similar products at home and abroad, and on the basis of research on manufacturing and production process in-depth, developed a new "festival," excellent performance "," double paste box machine.
This machine adopts double servo feeding, ensure that the equipment in the stability of high speed paper feeding and high-speed feed synchronization, and servo feed can make A,B piece set feeding size individually , so as to solve the problem of size.
Double gluing is used for gluing, respectively hot melt adhesive and ordinary sealant, which ensures the 100% bonding of the product into the container and cold storage.
The double servo positioning is also used in the two piece butt joint, which provides the same consistency for low speed bonding and high speed bonding of the machine.
This machine can be used as a flat box and a special shaped box, the front positioning of our company's original, the use of dual-use specifications, shorten the time for the machine to change order .
The machine is a dual function machine, both the double box and the single box can be produced. It is only 2 minutes to complete the conversion from double box to single box.
II.Machine parameters and configuration list
Feeding size: Max 1200*1200 Min 500*450
Applicable paper range: A-E corrugated and less than 6mm corrugated board
Design speed: 0-3000pcs/h
Dimensions(L*W*H) 6940*4200*1310(Vertical compression)
Heating power: 2KW
Total power: 9KW
Machine manufacturing process: Box Producing Process: Customer Visit: Related Products:
| HX-2400B folder gluer |
|Components and parts ||brand |
|Button ||French schneider |
|Contactor ||French schneider,Taiwan Tiande |
|Servo motor ||Beijing Zhongchuang |
| Main frequency converter || Taiwan Delta |
| PLC || Taiwan Delta |
| Touch screen || Taiwan Delta |
| Photoelectricity || Taiwan Delta, |
| Key position bearing || England FKG |
| Main motor || Shanghai Saini |
| Reducer || Taiwan Chengbang(CPg) |
| Micromotor ||Xiamen Jingyan(Sino German joint venture) |
| Suction belt || Swiss Rui Baolong |
| Press belt || German siegling |
| Transportation belt || German siegling |
|cylinder ||Taiwan AirTAC |
Welcome to contact us and visit us, we'd like to offer you best machines, make friends with you forever! Carina
