Adjustment of 360 Degree
160 Piece/Min
Can Be Choose
Engineers Available to Service Machinery Overseas
1-5color Optional
Both Can Be Optional
CZXY-1200X2800
Satellite
Printing,Slotting and Cutting
One Year
Schneider
Plastic Film, Container
customized as customer need
CZXY
Hebei, China
8441809000
10sets/Month
Available | Customized Request
1 | Machine size | MM | 1200X2800 |
2 | Max paper size | MM | 1200X2600(Continuous paper) |
3 | Min paper size | MM | 400*600 |
4 | Max printing area | MM | 1200X2400 |
Max slotting area | MM | 1200X2400 | |
Min slotting size | MM | 380 | |
5 | Min die cutting size | MM | 380 |
6 | Max die cutting area | MM | 1200X2400 |
7 | Printng roller and die cutter roller traverse | MM | 10 both left and right |
8 | anilox roll manual adjustment upper and lower | MM | 0~11 |
9 | Lower printing roll manual adjustment upper and lower | MM | 0~11 |
10 | Rubber roller automatic traverse | MM | 20 both left and right |
11 | Printing roller, rotary die cutting roller, rubber roller body ratation | degree | 360 |
12 | Economic speed | P/min | 120 |
13 | Feeding rubber roller | Φ | 156 |
14 | Printing roller diameter | Φ | 410(include printing plate) |
15 | Wall of machine | HT200 | 50MMthickness |
16 | Driving gear | 20GrMnTi | Hardness 60, fine grinding, transmission gear thickness 50mm |
17 | Paper feeding precision | ±1.0mm | |
18 | Die cutting precision | ±1.0mm | |
19 | Main motor power | 15KW | |
20 | Production power | 26KW | |
21 | Total power | 33KW |
Stacking unit (optional)
1, the choice of manual or operation.
2 bed units lift driven by strong chain.
3, the stack height is 1600mm.
4, flat wrinkles climbing belt, to prevent the cardboard decline.
5, when the pressure action bin baffle stacked in cardboard tray connected to the book highly extendable, hold the cardboard.
Six gear transmission
1), smooth operation, low noise, hardness HRC50-55, long life, wear a small, long-term guarantee the accuracy of printed chromatic unchanged.
2), the phase gear using 45 steel, quenched and tempered, high-frequency hardening, hobbing finishing, hardness HRC50-55.
7, lubrication
1), each unit with gear pump oil to achieve circular spray lubrication.
2), with the storage tank
Eight, the main technical parameters
1, the machine maximum mechanical speed: 100 (pcs / min)
2, the maximum feed size: 1250mm × 2400mm
3, the minimum feed size: 350mm (full version) × 800mm
4, the maximum printing area: 1250mm × 2400mm
5, the standard plate thickness: 4mm or 6mm
6, the printing precision: ≤ ± 0.75mm (four-color)
Machine more details:1 | Machine size | MM | 1200X2800 |
2 | Max paper size | MM | 1200X2600(Continuous paper) |
3 | Min paper size | MM | 400*600 |
4 | Max printing area | MM | 1200X2400 |
Max slotting area | MM | 1200X2400 | |
Min slotting size | MM | 380 | |
5 | Min die cutting size | MM | 380 |
6 | Max die cutting area | MM | 1200X2400 |
7 | Printng roller and die cutter roller traverse | MM | 10 both left and right |
8 | anilox roll manual adjustment upper and lower | MM | 0~11 |
9 | Lower printing roll manual adjustment upper and lower | MM | 0~11 |
10 | Rubber roller automatic traverse | MM | 20 both left and right |
11 | Printing roller, rotary die cutting roller, rubber roller body ratation | degree | 360 |
12 | Economic speed | P/min | 120 |
13 | Feeding rubber roller | Φ | 156 |
14 | Printing roller diameter | Φ | 410(include printing plate) |
15 | Wall of machine | HT200 | 50MMthickness |
16 | Driving gear | 20GrMnTi | Hardness 60, fine grinding, transmission gear thickness 50mm |
17 | Paper feeding precision | ±1.0mm | |
18 | Die cutting precision | ±1.0mm | |
19 | Main motor power | 15KW | |
20 | Production power | 26KW | |
21 | Total power | 33KW |
Stacking unit (optional)
1, the choice of manual or operation.
2 bed units lift driven by strong chain.
3, the stack height is 1600mm.
4, flat wrinkles climbing belt, to prevent the cardboard decline.
5, when the pressure action bin baffle stacked in cardboard tray connected to the book highly extendable, hold the cardboard.
Six gear transmission
1), smooth operation, low noise, hardness HRC50-55, long life, wear a small, long-term guarantee the accuracy of printed chromatic unchanged.
2), the phase gear using 45 steel, quenched and tempered, high-frequency hardening, hobbing finishing, hardness HRC50-55.
7, lubrication
1), each unit with gear pump oil to achieve circular spray lubrication.
2), with the storage tank
Eight, the main technical parameters
1, the machine maximum mechanical speed: 100 (pcs / min)
2, the maximum feed size: 1250mm × 2400mm
3, the minimum feed size: 350mm (full version) × 800mm
4, the maximum printing area: 1250mm × 2400mm
5, the standard plate thickness: 4mm or 6mm
6, the printing precision: ≤ ± 0.75mm (four-color)
Machine more details:
