Carton box packaging printing machine for cardboard making
1 Whole machine electric parts was choice the domestic famous brand, good quality and steady.
2 Complete machine baffle and important parts used the temper for decrease the metal internal force; and that parts are made by high precision processing center and grinded by digit controlled grinder.
3 All the transmission axles and rollers are made by high-quality steel, and processed through temper and dynamic balance ; plated with rigid chrome and grinded surface.
4 All the transmission gears was used the 45# alloy steel, which is grinded after heat-treatment, and it was made by rubbing, it still maintains the high topping precision.
5 The whole machine undergoes the spray lubrication, intuitionist show setting, setting the double oil pipe balance system.
6 Option: Presetting adjustment function, feeding, printing, slotting, zero setting, memory reposition automatic.
7 Whole machine working interval adjustment, self-lock worm wheel and worm device, fast and convenient.
8 Option the vacuum adsorption, kick feeding or lead edge feeding to the customer request.
Option: Anilox roller, And stacker Machine.
Technical Parameter:
| YFQ480×1800 | 1447×2000 | 1447×1800 | 0-60 Piece/min | 5.5kw |
| YFQ480×2000 | 1447×2200 | 1447×2000 | 0-60 Piece/min | 5.5kw |
| YFQ480×2400 | 1447×2600 | 1447×2400 | 0-60 Piece/min | 5.5kw |
| YFQ480×2600 | 1447×2800 | 1447×2600 | 0-60 Piece/min | 5.5kw |
Delivery pictures: Carton box pictures: Factory process: Related Products:
Welcome to contact us for more details and videos
