High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming

Quantity:
High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming
High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming
High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming
High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming
High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming
High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming
  • Electric

  • Engineers Available to Service Machinery Overseas

  • Carton Packaging Machinery

  • Semi-Automatic

  • Imported Brand

  • Omron Brand

  • Taiwan Technology

  • Taiwan Brand

  • Germany Tungsten Steel

  • One Minute

  • All Available

  • Automatically,

  • by Touch Screen

  • 3ply and 5ply

  • Taiwan Brand

  • Standard Abroad Packaging, Container

  • 2000

  • CZXY

  • Hebei, China

  • 8441809000

  • 20days/Set

  • Available | Customized Request

High quality double servo stitcher for two pieces bigger box forming

High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming

High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming

High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming
High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming

Yaskawa Japan imported four servo drives with accurate accuracy and reduced mechanical transmission, which can effectively reduce the mechanical failure rate.
The entire control system of the stitching machine uses the Omron PLC control system.
The contactors in the control box are all made by the Taiwan Shilin brand and the French Schneider brand, and the photoelectric adopts the Japanese Omron brand.
The bottom mold, the blade is made of Japanese tungsten steel (wear resistant).
Stitching machine complete set of stitcher heads, all made of special steel, CNC precision machining.
Changing the carton size and adjusting the carton nail distance can be done in just one minute, greatly improving efficiency.
There is automatic counting function in the back section, and the number of finished products can be sent to the end of the conveying machine in a set number (1-99), which is convenient for packing and binding.
Mechanical speed: 500 nails per minute.
Nail distance: 30-120mm can be adjusted at will.
One machine for dual use, can stitch single-piece carton, double-piece carton, irregular carton.
The size is fully automatic and it takes only 2-3 minutes to change size.
Can stitch strengthen nail, single nail, double row nail, once completed.
The paper feeding section automatically counts and the finished product is sent out and bundled.
Adjust the nail distance, use the computer to set the automatically nail distance adjustment, the nail distance is adjustable from 20-120mm.
Electric baffle, adjust the size of the flap.
Applicable to five layers of corrugated board, seven layers (high weight).
This machine uses four servo motors (two head motors and two control nail distance motors)
The bottom mold feed width is 60mm (with two standard bottom plates)
.:

Model and parameters SDJ-2500 SDL-3000 SDJ-3500 SDJ-4000
Max paper size (A+B)*2(mm) 4000 4800 6000 7000
Min paper size (A+B)*2(mm) 1060 1060 1060 1060
Max carton box length A(mm) 1850 2350 2850 3350
Min carton box length A(mm) 350 350 350 350
Max carton box width B(mm) 1000 1200 1500 1800
Min carton box width B(mm) 180 180 180 180
Max carton box height (C+D+C) (mm) 2500 2500 2500 2500
Min carton box height (C+D+C) (mm) 400 400 400 400
Max.flap size C(mm) 560 560 560 560
Min. flap sizeC(mm) 50 50 50 50
Max height D(mm) 2000 2000 2000 2000
Min height D(mm) 150 150 150 150
Max width of tongue(mm) 45 45 45 45
Nail distance(mm) 30-120 30-120 30-120 30-120
Nail quantity 1-99 1-99 1-99 1-99
Stitching speed(times/min) 500 500 500 500
Machine weight 2.5 3 3.5 5



Machine details:

High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming

Box Producing Process:

High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming

Customer Visit:

High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming

Related Products:

High Quality Double Servo Stitcher for Two Pieces Bigger Box Forming

Welcome to contact us and visit us, we'd like to offer you best machines, make friends with you forever!
